Solid-liquid separator
+
  • Description
  • KLGY-type integrated solid-liquid separator is a device that integrates screw grid machine, slag discharge machine, sand conveying screw and other machinery. Feces and sewage first enter the sedimentation area, where solids with large specific gravity settle. Sediment, together with mud and sand conveyed by the sand conveying screw, is lifted, pressed and dewatered by the slag discharge machine and discharged from the discharge port. Feces and sewage flow through the sedimentation area into the grid area, flow through the spiral grid machine, the debris larger than the grid distance is trapped, the slag falls into the central hopper, and is discharged from the discharge port after screw conveying, squeezing and dewatering. After the feces and sewage of the spiral grid machine flow through the grid area and then flow out of the machine to achieve solid-liquid separation. The solid slag discharged from the spiral grille machine and the slag discharge machine falls into other collection devices and is transported away.
    KLGY-type integrated solid-liquid separator realizes the functions of solid-liquid separation, sand removal, transmission and pressing and dewatering at the same time. The whole operation process is concentrated in a relatively closed stainless steel box, no odor leakage, small footprint, stable operation, almost no maintenance. This machine is mainly used for feces receiving station, municipal sewage and so on.


    Engineering Performance

    ● Beijing Tiantongyuan septic tank manure treatment project

    ● Shandong Rongcheng septic tank manure treatment project

    ● Livestock and poultry manure treatment project of Hohhot Mont Breeding Group

    ● Jilin Yanji septic tank manure treatment project

    ● Shandong Weifang septic tank manure treatment project

    ● Xiamen Manure Landscaping Garbage Treatment Project

    Technical parameters

    (1) the host box is 304 stainless steel
    (2) The main shaft and spiral blade of the auger are stainless steel
    (3) The filter screen is a wedge-shaped 304 stainless steel strip filter screen, and the gap is 0.25mm,0.5mm,0.75mm, and 1.0mm according to the different processing materials.
    (4) The frame is made of channel steel and angle steel

    Liquid matter (solid content <50%) treats 4-8 cubic meters of cow dung (and cow dung biogas slurry), 4-8 cubic meters of chicken dung, 4-8 cubic meters of pig dung and 4-8 cubic meters of biogas slurry per hour. Solid matter according to the material viscosity and dry humidity processing speed difference is generally 2-6 cubic.
    Processing capacity varies according to local

Solid-liquid separator

KLGY-type integrated solid-liquid separator is a device that integrates screw grid machine, slag discharge machine, sand conveying screw and other machinery. Feces and sewage first enter the sedimentation area, where solids with large specific gravity settle. Sediment, together with mud and sand conveyed by the sand conveying screw, is lifted, pressed and dewatered by the slag discharge machine and discharged from the discharge port. Feces and sewage flow through the sedimentation area into the grid area, flow through the spiral grid machine, the debris larger than the grid distance is trapped, the slag falls into the central hopper, and is discharged from the discharge port after screw conveying, squeezing and dewatering. After the feces and sewage of the spiral grid machine flow through the grid area and then flow out of the machine to achieve solid-liquid separation. The solid slag discharged from the spiral grille machine and the slag discharge machine falls into other collection devices and is transported away.
  • Description
  • KLGY-type integrated solid-liquid separator is a device that integrates screw grid machine, slag discharge machine, sand conveying screw and other machinery. Feces and sewage first enter the sedimentation area, where solids with large specific gravity settle. Sediment, together with mud and sand conveyed by the sand conveying screw, is lifted, pressed and dewatered by the slag discharge machine and discharged from the discharge port. Feces and sewage flow through the sedimentation area into the grid area, flow through the spiral grid machine, the debris larger than the grid distance is trapped, the slag falls into the central hopper, and is discharged from the discharge port after screw conveying, squeezing and dewatering. After the feces and sewage of the spiral grid machine flow through the grid area and then flow out of the machine to achieve solid-liquid separation. The solid slag discharged from the spiral grille machine and the slag discharge machine falls into other collection devices and is transported away.
    KLGY-type integrated solid-liquid separator realizes the functions of solid-liquid separation, sand removal, transmission and pressing and dewatering at the same time. The whole operation process is concentrated in a relatively closed stainless steel box, no odor leakage, small footprint, stable operation, almost no maintenance. This machine is mainly used for feces receiving station, municipal sewage and so on.


    Engineering Performance

    ● Beijing Tiantongyuan septic tank manure treatment project

    ● Shandong Rongcheng septic tank manure treatment project

    ● Livestock and poultry manure treatment project of Hohhot Mont Breeding Group

    ● Jilin Yanji septic tank manure treatment project

    ● Shandong Weifang septic tank manure treatment project

    ● Xiamen Manure Landscaping Garbage Treatment Project

    Technical parameters

    (1) the host box is 304 stainless steel
    (2) The main shaft and spiral blade of the auger are stainless steel
    (3) The filter screen is a wedge-shaped 304 stainless steel strip filter screen, and the gap is 0.25mm,0.5mm,0.75mm, and 1.0mm according to the different processing materials.
    (4) The frame is made of channel steel and angle steel

    Liquid matter (solid content <50%) treats 4-8 cubic meters of cow dung (and cow dung biogas slurry), 4-8 cubic meters of chicken dung, 4-8 cubic meters of pig dung and 4-8 cubic meters of biogas slurry per hour. Solid matter according to the material viscosity and dry humidity processing speed difference is generally 2-6 cubic.
    Processing capacity varies according to local
